Engine · The Seal
Gaskets
Our cylinder head gasket is a true MLS (multi-layer steel) assembly: five layers of 300-series stainless steel sandwiched together, with embossed beads pressed around the cylinder bores and every coolant and oil passage. The outer two layers are Viton-coated, a fluoroelastomer rubber that conforms to the surface finish of the head and block at install, then stays put through the heat cycling that opens up composite gaskets. The centre shim layer is plain stainless, varied in thickness to set deck height. No sealant, no retorquing, no liquid copper.
- Multi-layer steel construction. Five layers of 300-series stainless sandwiched together.
- Embossed sealing beads around every cylinder bore and coolant passage.
- Viton fluoroelastomer coating on the outer layers. Rated to 482°F sustained.
- Stopper layer where the application requires it. Limits bead compression near the bore.
- OEM bolt pattern, OEM bore diameter, OEM oil and coolant passages.
- No sealant required. Install dry, torque to spec, button it up.
